98.css – A design system for building faithful recreations of old UIs

98.css

A design system for building faithful recreations of old UIs.

Intro

98.css is a CSS library for building interfaces that look like Windows 98.

See more on GitHub.

Hello, world!

This library relies on the usage of semantic HTML.To make a button, you’ll need

to use a

.Input elements require labels.Icon buttons rely on

aria-label

.This page will guide you through that process, but accessibility is a primary

goal of this project.

You can override many of the styles of your elements while maintaining the appearance provided by this library.Need more padding on your buttons? Go for it.

Need to add some color to your input labels? Be our guest.

This library does not contain any JavaScript, it merely styles your HTML with some CSS.This means 98.css is compatible with your frontend framework of choice.

Here is an example of 98.css used with React, and

an example with vanilla JavaScript.

The fastest way to use 98.css is to import it from unpkg.

https://unpkg.com/98.css”

>

You can install 98.css from the GitHub releases page, or from npm.

npm install 98.css

Components

Button

A command button, also referred to as a push button, is a control that causes the application to perform some action when the user clicks it.

A standard button measures 75px wide and 23px tall, with a raised outer and inner border.They are given 12px of horizontal padding by default.

Show code

Click me

When buttons are clicked, the raised borders become sunken.The following button is simulated to be in the pressed (active) state.

Show code

I am being pressed

Disabled buttons maintain the same raised border, but have a “washed out” appearance in their label.

Show code

I cannot be clicked

Button focus is communicated with a dotted border, set 4px within the contents of the button.The following example is simulated to be focused.

Show code

I am focused

Checkbox

A check box represents an independent or non-exclusive choice.

Checkboxes are represented with a sunken panel, populated with a “check” icon when selected, next to a label indicating the choice.

Note: You must include a corresponding label after

your checkbox, using the

element with a for

attribute

pointed at the id

of your input.

This ensures the checkbox is easy to use with

assistive technologies, on top of ensuring a good user experience for all (navigating with the tab key,

being able to click the entire label to select the box).

Show code

This is a checkbox

Checkboxes can be selected and disabled with the standard checked

and disabled

attributes.

When grouping inputs, wrap each input in a container with the field-row

class.This ensures

a consistent spacing between inputs.

Show code

OptionButton

An option button, also referred to as a radio button, represents a single choice within a limited set of mutually exclusive choices.

That is, the user can choose only one set of options.

Option buttons can be used via the radio

type on an input element.

Option buttons can be grouped by specifying a shared name

attribute on each

input.Just as before: when grouping inputs, wrap each input in a container with the

field-row

class to ensure a consistent spacing between inputs.

Show code

Option buttons can also be checked

and disabled

with their corresponding

HTML attributes.

Show code

GroupBox

A group box is a special control you can use to organize a set of controls.A group box is a rectangular frame with an optional label that surrounds a set of controls.

A group box can be used by wrapping your elements with the fieldset

tag.

It contains a sunken outer border and a raised inner border, resembling an engraved box

around your controls.

Show code

You can provide your group with a label by placing a legend

element

within the fieldset

.

Show code

TextBox

A text box (also referred to as an edit control) is a rectangular control where the user enters or edits text.It can be defined to support a single line or multiple lines of text.

Text boxes can rendered by specifying a text

type on an

input

element.

As with checkboxes and radio buttons, you

should provide a corresponding label with a properly set for

attribute, and wrap both in a container with the field-row

class.

Show code

Additionally, you can make use of the field-row-stacked

class

to position your label above the input instead of beside it.

Show code

To support multiple lines in the user’s input, use the textarea

element instead.

Show code

Text boxes can also be disabled and have value with their corresponding HTML attributes.

Show code

Other types of HTML5 text inputs are also supported.

Show code

Slider

A slider, sometimes called a trackbar control, consists of a bar that defines the extent or range of the adjustment and an indicator that shows the current value for the control…

Sliders can rendered by specifying a range

type on an

input

element.

Show code

You can make use of the has-box-indicator

class replace the

default indicator with a box indicator, furthermore the slider can be wrapped

with a div

using is-vertical

to display the input vertically.

Note: To change the length of a vertical slider, the input

width

and div

height.

Show code

Dropdown

A drop-down list box allows the selection of only a single item from a list.In its closed state, the control displays the current value for the control.The user opens the list to change the value.

Dropdowns can be rendered by using the select

and option

elements.

Show code

5 – Incredible!4 – Great!3 – Pretty good2 – Not so great1 – Unfortunate

By default, the first option will be selected.

You can change this by

giving one of your option

elements the selected

attribute.

Show code

5 – Incredible!4 – Great!3 – Pretty good2 – Not so great1 – Unfortunate

Window

The following components illustrate how to build complete windows using 98.css.

Title Bar

At the top edge of the window, inside its border, is the title bar (also reffered to as the caption or caption bar), which extends across the width of the window.The title bar identifies the contents of the window.

Include command buttons associated with the common commands of the primary window in the title bar.These buttons act as shortcuts to specific window commands.

You can build a complete title bar by making use of three classes,

title-bar

, title-bar-text

, and title-bar-controls

.

Show code

We make use of aria-label

to render the Close button, to let

assistive technologies know the intent of this button.

You may also use

“Minimize”, “Maximize”, “Restore” and “Help” like so:

Show code

You can make a title bar “inactive” by adding inactive

class,

useful when making more than one window.

Show code

Window contents

Every window has a boundary that defines its shape.

To give our title bar a home, we make use of the window

class.

This provides a raised outer and inner border, as well as some

padding.We can freely resize the window by specifying a width in the

container style.

Show code

To draw the contents of the window, we use the window-body

class under the title bar.

There’s so much room for activities!

Show code

Status Bar

A status bar is a special area within a window, typically the bottom, that displays information about the current state of what is being viewed in the window or any other contextual information, such as keyboard state.

You can render a status bar with the status-bar

class,

and status-bar-field

for every child text element.

There are just so many possibilities:

– A Task Manager

– A Notepad

– Or even a File Explorer!

Show code

TreeView

A tree view control is a special list box control that displays a set of objects as an indented outline based on their logical hierarchical relationship.

To render a tree view, use an ul

element with the

tree-view

class.The children of this list (li

elements), can contain whatever you’d like.

– We can put

– ✨ Whatever ✨

– We want in here

Show code

• We can put
• ✨ Whatever ✨
• We want in here

To make this a tree, we can nest further ul

elements

(no class needed on these).

This will provide them with a nice dotted

border and indentation to illustrate the structure of the tree.

To create expandable sections, wrap child lists inside of

details

elements.

– Table of Contents

– What is web development?

–

CSS

– Selectors

– Specificity

– Properties

–

JavaScript

– Avoid at all costs

–

Unless

– Avoid

–

At

– Avoid

– At

– All

– Cost

– All

– Cost

– HTML

– Special Thanks

Show code

• Table of Contents
• What is web development?

• CSS

  • Selectors
  • Specificity
  • Properties
• JavaScript

  • Avoid at all costs
  • Unless

    • Avoid
    • At

      • Avoid
      • At
      • All
      • Cost
    • All
    • Cost
• HTML
• Special Thanks

Tabs

A tab control is analogous to a divider in a file cabinet or notebook.You can use this control to define multiple logical pages or sections of information within the same window.

To render a tab list, use a menu

element with the

[role=tablist]

attribute.The children of this menu (li

elements), should get a [role=tab]

attribute.

Tabs should be managed by adding custom javascript code.

All you need is to add the [aria-selected=true]

attribute to the active tab.

Hello, world!

the tab content

Show code

To create multirows tabs, add a multirows

class to the menu

tag.

Hello, world!

the tab content

Show code

TableView

To render a table view, use a table element.Wrap it with a div element with sunken-panel

class to provide proper border and overflow container.

With a bit of extra scripting you can make table view interactive.

Give interactive

class to

table element to show pointer cursor when hovering over body rows.Table rows can be given

highlighted

class to appear selected.

Name | Version | Company |

—|—|—|

MySQL ODBC 3.51 Driver | 3.51.11.00 | MySQL AB |

SQL Server | 3.70.06.23 | Microsoft Corporation |

SQL Server | 3.70.06.23 | Microsoft Corporation |

SQL Server | 3.70.06.23 | Microsoft Corporation |

SQL Server | 3.70.06.23 | Microsoft Corporation |

SQL Server | 3.70.06.23 | Microsoft Corporation |

SQL Server | 3.70.06.23 | Microsoft Corporation |

SQL Server | 3.70.06.23 | Microsoft Corporation |

SQL Server | 3.70.06.23 | Microsoft Corporation |

SQL Server | 3.70.06.23 | Microsoft Corporation |

Show code

Issues, Contributing, etc.

98.css is MIT licensed.

Refer to the GitHub issues page to see bugs

in my CSS or report new ones.I’d really like to see your pull requests (especially those new to

open-source!) and will happily provide code review.98.css is a fun, silly project and I’d like

to make it a fun place to build your open-source muscle.

Thank you for checking my little project out, I hope it brought you some joy today.
